Order 4152-BSS by Blue Sea Systems WeatherDeck SPDT On-Off-On Toggle Switch

info@USMegaStore.com

+1 (838) 222-2203
+1 (718) 504-5719 (Intl.)

Options and Related Products

Features:

Specially manufactured by Carling Technologies for use in Blue Sea Systems' WeatherDeck® Panels
When mounted with a WeatherDeck® Toggle Switch Boot Rated IP67-temporary immersion for 30 minutes
Nickel-plated brass and phenolic non-corrosive construction

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Action	On-Off-On
Pole / Throw	SPDT
Poles	1
Common Applications	combining nav lights or anchor light with independent bulbs
Maximum Amperage	15A at 125V AC 15A at 12V DC 10A at 250V AC
Terminal Type	Quick Connect Tab
Number of Terminals	3
Terminal Size	0.25in (6.35 mm)
Weight	0.10lb (0.05 kg)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Action	On-Off-On
Pole / Throw	SPDT
Poles	1
Common Applications	combining nav lights or anchor light with independent bulbs
Maximum Amperage	15A at 125V AC 15A at 12V DC 10A at 250V AC
Terminal Type	Quick Connect Tab
Number of Terminals	3
Terminal Size	0.25in (6.35 mm)
Weight	0.10lb (0.05 kg)

Note: Please read description carefully. Do not base your order on the picture presented.
