Key Characteristics |
Trade Name | Code Reader™ |
Brand Name | Code Corporation |
Country of Origin | Malaysia |
HTS Code (Harmonized Tariff Schedule) | 8471.60.8000 |
ECCN (Export Commodity Control Number) | EAR99 |
Dimensions |
Dimensions | 5.5 in H x 2 in W x 2.75 in D |
Height | 5.5 in |
Width | 2 in |
Depth | 2.75 in |
Cable Length | 6 ft |
Weight | 0.25 lb |
Material Characteristics |
Color | Black |
Product Features |
Application | Asset Tracking, Barcode Labeling, Circuit Board Labeling, General Identification |
Shipped With Battery | No |
Connectivity Options | USB 2.0 (generic HID, HID keyboard, virtual com port) |
Memory | 1 MB NOR Flash, 16MB RAM |
Scanner Model | CR950 |
Battery Type | No Battery |
Decode Capability - 1D | Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, GS1 DataBar, Hong Kong 2 of 5, IATA 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, MSI Plessey, NEC 2 of 5, Straight 2 of 5, Telepen, Trioptic, UPC / EAN / JAN |
Rotational Tolerance | +/- 180° |
Sensor | CMOS 1.2 megapixel monochrome |
Field of View | 51° Horizontal by 39.4° Vertical |
Optical Resolution | 1280 x 960 |
Pitch | ± 65° (from front to back) |
Skew | ± 60° from plane parallel to symbol (side-to-side) |
Target Beam | Single Blue targeting bar (470nm) |
Image Output Options | JPEG, PGM |
Decode Capability - 1D Stacked | GS1 Composite (CC-A/CC-B/CC-C), MicroPDF, PDF417 |
Decode Capability - 2D | Aztec Code, Data Matrix, Data Matrix Rectangular Ext'n, GoCode® (prorietary--add'l license req'd), Micro QR Code, QR Code, QR Model 1 |
Decode Capability - Postal | Australian Post, Canada Post, Itelligent Mail, Japan Post, KIX Code, Korea Post, Planet, Post-Net, UK Royal Mail, UPU ID-tags |
Field Selection | High Density |
Ambient Light Immunity | Sunlight: Up to 9,000ft-candles/96,890 lux |
Charging Station w/BT Radio Communication Interfaces for Barcode Scanners | USB 2.0 (generic HID, HID keyboard, virtual com port) |
Reader/Scanner Unit Communication | USB 2.0 (Generic HID, HID keyboard, Virtual COM port) |
Printing Specifications |
Device Drop Test & Durability | Resistant to 6-foot drops |
Compliance |
UNSPSC | 43211701 |
Ingress Protection Rating | IP54 |
RoHS Compliance Status | Compliant with Directive 2011/65/EU and 2015/863 |
