Burndy FP6 6000 psi Manual Hydraulic Foot Pump

Operating Pressure: 6,000 PSI
  • Brand Burndy
  • Part # FP6
  • Condition
    Brand New
Availability
4-6 Weeks Factory Lead Time
Check Availability
Quantity
Share:

Options and Related Products

Operating Pressure:
Operating Pressure: 6,000 PSI

Burndy, FP6, 6000 psi Manual Hydraulic Foot Pump

Foot pumps are designed to match the output pressure requirements for use with all Hypress™ heads and cutters. Each pump is equipped with a built-in, factory set pressure release valve with audible click to signal completion of a crimp cycle.

Features:

  • Diamond Plate Steel Foot Pad
  • Long Arm
  • Spring Loaded Arm
  • Built-In Factory Set Pressure Relief Valve
  • Quick Disconnect Hydraulic Fitting
  • Lightweight Rugged Design Portable
  • Sturdy Leg Stabilizers
Benefits:

  • Easy to lift and carry
  • Durable. Long life expectancy.
  • Easy to transport and move tool around job site with built in handle.
  • Easy operation provided with spring assisted return arm.
  • Maximum mechanical advantage provided with long arm extending beyond pump body.
  • Quality, heavy duty foot pad provided with diamond plate steel.
  • Solid tool base provided with sturdy broad leg stabilizers.
  • Time saving quick disconnect hydraulic fitting.
  • High quality crimps provided with factory set pressure release valve with audible click to signal completion of crimp.
See more product information See less
Return and Warranty

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Distributor

Technical Details

Reviews
Dimensional
Height (in)Closed height: 6-1/2"Height (with handle open): 17"
Width (in)5
Length (in)24-3/4
General
Weight lbs19
Product DescriptionManual Hydraulic Foot Pump, 6000 PSI, 1-1/8 qts Reservoir Volume
Approvals / Certifications
ROHS CompatibleCompliant
CULUSN
Physical
Pressure (Operating)6000
Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details
Dimensional
Height (in)Closed height: 6-1/2"Height (with handle open): 17"
Width (in)5
Length (in)24-3/4
General
Weight lbs19
Product DescriptionManual Hydraulic Foot Pump, 6000 PSI, 1-1/8 qts Reservoir Volume
Approvals / Certifications
ROHS CompatibleCompliant
CULUSN
Physical
Pressure (Operating)6000
Note

Note: Please read description carefully. Do not base your order on the picture presented.
