| Application | Wire Termination |
| Color Code | Gray |
| Connector Type | Standard Barrel |
| Die Index | 8 |
| EU RoHS Indicator | Yes |
| Feature - Barrel Style | Chamfered |
| Feature - Barrel Type | Standard |
| Finish Type | Tin-Plated |
| Material | Copper |
| Physical Attribute - Number of Holes | 1 |
| Physical Attribute - Tongue Type | Standard |
| Plated | Y |
| Plating Type | Tin - Electro Plated |
| Temperature Rating | 194 |
| Type | Standard Barrel, Tin Plated |
| Dimension - B Length fraction | 1/2 in |
| Dimension - B Length inch | 0.50 in |
| Dimension - Bolt Hole Size inch | 0.27 in |
| Dimension - Bolt Size fraction | 1/4 |
| Dimension - Bolt Size inch | 0.25 |
| Dimension - D inch | 0.64 in |
| Dimension - Hole Size fraction | 1/4 |
| Dimension - Hole Size inch | 0.27 in |
| Dimension - Hole Size mm | 6.9 mm |
| Dimension - L Length Overall mm | 37 mm |
| Dimension - Length Overall inch | 1.44 in |
| Dimension - N inch | 0.31 in |
| Dimension - Outside Diameter inch | 0.38 in |
| Dimension - Pad Width inch | 0.55 in |
| Dimension - Strip Length inch | 1/2 |
| Dimension - Stud Size inch | 1/4 |
| Dimension - Stud Size inch | 1/4 |
| Dimension - Z inch | 0.33 in |
| Physical Attribute - Tongue Angle | Straight |
| Voltage Rating | 35 kV |
| Voltage - Maximum | 35000 |
| Conductor - Copper DLO Size | 4 AWG |
| Conductor - Copper DLO Size Range | 4 AWG |
| Conductor - Copper Flex G Size | 4 AWG |
| Conductor - Copper Flex G Size Range | 4 AWG |
| Conductor - Copper Flex H Size | 4 AWG |
| Conductor - Copper Flex H Size Range | 4 AWG |
| Conductor - Copper Flex I Size | 4 AWG |
| Conductor - Copper Flex I Size Range | 4 AWG |
| Conductor - Copper Flex K Size | 4 AWG |
| Conductor - Copper Flex K Size Range | 4 AWG |
| Conductor - Copper Flex M Size | 4 AWG |
| Conductor - Copper Flex M Size Range | 4 AWG |
| Conductor - Copper Solid Size | 4 AWG |
| Conductor - Copper Solid Size Range | 4 AWG |
| Conductor - Copper Str Compact Size | 4 AWG |
| Conductor - Copper Str Navy Size | 40 |
| Conductor - Copper Str Navy Size Range | 40 (19) Navy-50 (19) Navy |
| Conductor - Copper Str Size | 4 AWG |
| Conductor - Copper Str Size Range | 4 AWG |
| Conductor - CopperWeld Str Size | 4 A AWG;4 D AWG;4 N AWG;4 P AWG |
| Conductor - CopperWeld Str Size Range | 4 A AWG-4 P AWG |
| Conductor - Material | Copper |
| Conductor Size | 4 AWG |
| Conductor Type | Code/Flex |
| Wire Size | 4 AWG |
| Buy America(n) Qualified | Buy American Act Compliant (All status valid till December 2024) |
| Certification - UL Recognized | No |
| Certification - cULus | No |
| Industry Standard(s) | UL 486A-486B |
