Dwyer, MMF-10-PV, Series MM Mini-Master Flowmeter, 1-10 SCFH Air, Bottom Mount Valve
Used to Indicate or Manually Control Air or Water
Offering advanced features at low cost, the Series MMflowmeters are ideal for a wide range of OEM and user application in medical equipment, air samplers, gas analyzers, pollution monitors, chemical injectors, cabinet purging, etc.
Where a compact flowmeter is required to measure small volume air flows, the Model MMF is recommended. Easy to mount, they require a minimum of panel space. A white back on the flow tube makes the ball float easy to see. The scale is highly visible and easy to read. Scale graduations are printed on aluminum alongside the flow tube (not on it), so the position of ball float is instantly visible.
The Model MMF's bezel type mounting is modern, attractive and quickly installed from the font of instrument panel. Two 1/4" OD mounting-connection tubes are integrally molded with flowmeter body. They can be back connected to flexible rubber or plastic tubing and held in place with two spring retainers which are furnished. If preferred, connections may be made to metal or rigid plastic tubing with a double compression fitting or nylon tube union such as Dwyer Part No. A-328.
Excellent repeatability and ±10% accuracy make the MMF flowmeter an excellent value at its low cost.
