Options and Related Products

Output:: Output: 5 VDC / 300mA

The Model PW 2 converts AC line voltage to regulated DC output. This compact power supply may be used to power various DC operated peripherals and input / output modules on PLC's, or transmitters in process control.

Features

Regulated-power outputs of 5 VDC.
120 V/60Hz input.
Screw-terminal connections.
Easily mounted in any plane.
Output DC voltages are isolated from AC line

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Voltage

Input

120 VAC ± 5%/60Hz (external fuse recommended)

Output

5V ± 0.2VDC / 300mA

Output Ripple Voltage

No Load - 2mVp-p
Max Load - 1.1mVp-p

General

Operating temperature

32 to 131°F (0 to 55°C)

Max. Humidity

95% RH, noncondensing

Mounting

side or base

Isolation Breakdown Voltage

3KVAC

Weight

0.38 lb

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Voltage

Input

120 VAC ± 5%/60Hz (external fuse recommended)

Output

5V ± 0.2VDC / 300mA

Output Ripple Voltage

No Load - 2mVp-p
Max Load - 1.1mVp-p

General

Operating temperature

32 to 131°F (0 to 55°C)

Max. Humidity

95% RH, noncondensing

Mounting

side or base

Isolation Breakdown Voltage

3KVAC

Weight

0.38 lb

Note

Note: Please read description carefully. Do not base your order on the picture presented.
