Order HVPI-4PEGNW by Hoyt DC Voltmeter 4.5 LCD, Neg Green

info@USMegaStore.com

+1 (838) 222-2203
+1 (718) 504-5719 (Intl.)

Options and Related Products

Features

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Display
Digits	4-1/2 digits (±19999 counts)
Type	0.45" (11.4 mm) 7 segment high contrast LCD
Backlighting Optional	Green Negative
Polarity	automatic, "-" displayed
Annunciators	°F, °C, PSI, % user-selectable or V, A, KW, PF
Decimal Points	4 position, user selectable
Overrange	4 lower order digits blank for inputs >1999 & < -1999
Inputs
Voltage Ranges	0-10 VDC, 0-5 VDC or 0-200 mV DC
Configuration	single ended
Impedance	390KΩ
Performance
Accuracy	± (0.1% fs + 2 count)
Conversion Rate	3 per second
Normal Mode Rejection	>30 dB / 60 Hz.
Warmup	10 minutes typical
Temperature Coeff.	± 100 ppm per °C typical
Offset Range	-19999 to +19999
Gain Range	1-20000 counts above adjusted zero
Power Supply	12 VDC or 24 VDC regulated (selectable)
Optional Backlight	24 VDC at 35 mA
Environment
Operating Range	0 to 50 °C
Storage Range	-10 to 60 °C.
Mounting	Window mount
Connection	4 screw terminal (6 with backlight)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Display
Digits	4-1/2 digits (±19999 counts)
Type	0.45" (11.4 mm) 7 segment high contrast LCD
Backlighting Optional	Green Negative
Polarity	automatic, "-" displayed
Annunciators	°F, °C, PSI, % user-selectable or V, A, KW, PF
Decimal Points	4 position, user selectable
Overrange	4 lower order digits blank for inputs >1999 & < -1999
Inputs
Voltage Ranges	0-10 VDC, 0-5 VDC or 0-200 mV DC
Configuration	single ended
Impedance	390KΩ
Performance
Accuracy	± (0.1% fs + 2 count)
Conversion Rate	3 per second
Normal Mode Rejection	>30 dB / 60 Hz.
Warmup	10 minutes typical
Temperature Coeff.	± 100 ppm per °C typical
Offset Range	-19999 to +19999
Gain Range	1-20000 counts above adjusted zero
Power Supply	12 VDC or 24 VDC regulated (selectable)
Optional Backlight	24 VDC at 35 mA
Environment
Operating Range	0 to 50 °C
Storage Range	-10 to 60 °C.
Mounting	Window mount
Connection	4 screw terminal (6 with backlight)

Note: Please read description carefully. Do not base your order on the picture presented.
