| Camera |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Effective Pixel | 2560(H) x1440(V) |
| Min. Illumination | Color: 0.005 Lux @(F1.6, AGC ON) B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR |
| White Balance | Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC | Auto / Manual |
| WDR | 120dB |
| Digital Noise Reduction | 3D DNR |
| Backlight compensation | BLC |
| Shutter Speed | 1 ~ 1/30,000s |
| Day & Night | IR Cut Filter |
| Digital zoom | 16X |
| Focus Mode | Auto / Semiautomatic / Manual |
| Privacy Mask | 24 programmable privacy masks |
| Lens |
| Focal Length | 2.8 mm to 12 mm, 4x optical |
| Zoom Speed | Approx. 2 s (optical lens, wide-tele) |
| Angle of View | Horizontal field of view: 100° to 33° (Wide-Tele)Vertical field of view: 53° to 18° (Wide-Tele)Diagonal field of view: 119° to 37.5° (Wide-Tele) |
| Min. Working Distance | 10 ~1500mm (Wide-Tele) |
| Aperture Range | F1.6 ~ F2.7 |
| Pan and Tilt |
| Pan / Tilt Range | Pan: 0° to 330°; Tilt: 0° ~ 90° |
| Pan / Tilt Speed | Pan manual speed: 0.1° ~ 100°/s, Pan preset speed: 100°/sTilt manual speed: 0.1° ~ 100°/s, Tilt preset speed: 100°/s |
| Proportional Zoom | Support |
| Number of Preset | 300 |
| Power-off Memory | Support |
| Local Video and Audio |
| Network Interface | 1 RJ45 10 M/100 M Ethernet, PoE |
| Audio input / putput | 1-ch audio input and 1-ch audio output |
| Network |
| Max. Image Resolution | 2560x1440 |
| Frame Rate | 50Hz: 25fps (2560 x 1440, 2048 x 1536, 1920 x 1080, 1280 x 960, 1280 x 720)60Hz: 24fps (2560 x 1440), 30fps (2048 x 1536, 1920 x 1080, 1280 x 960, 1280 x 720) |
| Image Compression | Main Stream: H.265+/H.265/H.264+/H.264 |
| ROI encoding | Main stream, sub-stream, and third stream respectively support two fixed areas. |
| SVC | Support |
| Audio Compression | G.711alaw/G.711ulaw/G.722/G.726/MP2L2/PCM |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Simultaneous Live View | Up to 20 |
| API | Open-ended, support ONVIF, ISAPI, and CGI, support Third-Party Management Platform |
| SD Memory Card | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR |
| User/Host Level | Up to 32 users, 3 levels: Administrator, Operator and Use |
| Security Measures | User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| IR |
| IR Distance | Up to 66ft(20 m) |
| Smart IR | Support |
| General |
| Working Temperature/Humidity | -4°F ~140°F (-20°C ~ 60°C) 90% or less |
| Power Supply | 12 VDC & PoE, Max.: 12 W (Max. 3.9 W for IR) |
| Protection Level | IP66 Standard;TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension | Φ 5.15" x 4.00"(Φ 130.7 mm x 101.7 mm ) |
| Weight | Approx. 1.17Ibs (0.53Kg) |
