Order 2KD-3/4 by STC 3/4" NPT Fail Closed 316 SS Angle Seat Valve

info@USMegaStore.com

+1 (838) 222-2203
+1 (718) 504-5719 (Intl.)

Buy in Bulk 4 Applicable Promotion(s)

Buy 10 pcs, get 5% off
Save 5% each on STC 2KD-3/4 3/4" NPT Fail Closed 316 SS Angle Seat Valve when you purchase 10 or more
Buy 5 pcs, get 4% off
Save 4% each on STC 2KD-3/4 3/4" NPT Fail Closed 316 SS Angle Seat Valve when you purchase 5 or more
Buy 3 pcs, get 3% off
Save 3% each on STC 2KD-3/4 3/4" NPT Fail Closed 316 SS Angle Seat Valve when you purchase 3 or more
Buy 2 pcs, get 2% off
Save 2% each on STC 2KD-3/4 3/4" NPT Fail Closed 316 SS Angle Seat Valve when you purchase 2 or more

Quantity

Options and Related Products

STC, 2KD-3/4, 3/4" NPT Fail Closed 316 SS Angle Seat Valve w/ PTFE Seal & 50mm Air Actuator

3/4" NPT Double Acting Fail Closed 316 Stainless Steel Angle Seat Valve with PTFE Seal and 50mm Air Actuator

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Port (NPT)	3/4"
Standard	DN20
Orifice, mm	18
Actuator	50
Cv	9.5
A	60
R	35
P	1/8
K1	131
A1	137
L	75
T	16
Bi-directional Flow Inlet Above Seat Pressure @ 180 °C	0-240 PSI (0-1.6MPa)
Bi-directional Flow Inlet Below Seat Pressure @ 180 °C	0-240 PSI (0-1.6MPa)
Media Temperature	-5 to 356°F (-20 to 180°C)
Pilot Control Pressure	65-120 PSI
SW	32

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Port (NPT)	3/4"
Standard	DN20
Orifice, mm	18
Actuator	50
Cv	9.5
A	60
R	35
P	1/8
K1	131
A1	137
L	75
T	16
Bi-directional Flow Inlet Above Seat Pressure @ 180 °C	0-240 PSI (0-1.6MPa)
Bi-directional Flow Inlet Below Seat Pressure @ 180 °C	0-240 PSI (0-1.6MPa)
Media Temperature	-5 to 356°F (-20 to 180°C)
Pilot Control Pressure	65-120 PSI
SW	32

Note: Please read description carefully. Do not base your order on the picture presented.
