| Primary Power | DC 12V at3A-24V at1.5A, Power Max. 10W |
| RS-485 connection | RS-485 standard / OSDP V2.0/ 2.2x |
| CPU | 1.2 GHz Quad Core ARM Processor |
| NPU | 2.4 TOPs NPU |
| Memory | 1GB RAM + 8GB Flash |
| Camera | - Face Automatic Exposure
- Palm Automatic Exposure
- Face Tracking
- Palm Detection
- 50Hz/60Hz Anti-Flicker
- Dual Camera
- RGB Camera: CMOS, 2 MP resolution (Output image 720x960pixels)
- IR Carmera: Global shutter CMOS, 1.3 MP resolution (Output image 720x960pixels)
|
| Ethernet network connection | 10 Base-T/ 100 Base-TX, Auto MDI/ MDIX |
| Data Protection | - Complies with TLS 1.2 for end-to-end secure communication channel (Secured Communication between Standalone Terminal and Server)
- AES128 (Secured Communication between Standalone Terminal &OSDP Reader and Access Control Panel)
|
| Number of Ports | - 1xTCP/IP
- 1xRS-485
- 4ch TTL Inputs
- 1ch TTL Output
- 3 relays
|
| Inputs | Wiegand, Button, Sensor, Aux |
| Outputs | Wiegand, 3 relays with dry contacts (Lock, Alarm, Bell) |
| Normally Open Contact Rating | 5A at30Vdc resistive |
| Normally Closed Contact Rating | 5A at30Vdc resistive |
| Operating Frequency/ Standard | - 13.56MHz: ISO14443 types A&B, ISO 15693
- 2.4GHz Bluetooth
|
| Tamper Switch | Magnetic tamper detection system |
| On-Board Monitor | Size: 2.4", Resolution: 240x320, Touch Screen, TFT |
| Audio Indicator | Internal speaker with adjustable intensity (Configurable on UI) |
| MIC | Supported |
| Video Phone | Support Standard SIP V2.0 |
| User Capacity | 50,000 |
| RFID Card Capacity | 50,000 (1:N) / 50,000 (1:1) |
| Maximum RFID Card Number Length | Wiegand In and Out (up to 64 bits) |
| Face Capacity | 10,000 (1:N) / 50,000 (1:1) |
| Palm Capacity | 5,000 (1:N) / 20,000 (1:1) |
| RFID Reading Distance | 13.56MHz and 125kHz: Up to 1.96"/ 50 mm (depending on environment and transponder) |
| Face Authentication Distance | 15.7" - 55.1" (40cm - 140cm) |
| Face Authentication Posture Adaptability | Yaw ≤ 30°, Pitch ≤ 30°, Roll ≤45° |
| Face Authentication Accuracy | - True Accept Rate (TAR) = 99%
- False Accept Rate (FAR) = 0.01%
|
| Face Authentication Mode | 1:1, 1:N |
| Face Authentication Speed | < 100ms (Field Test Result) |
| Face Authentication Liveness Detection | Yes (Infrared-visible light mode, Infrared Light Mode) |
| Face Mask Detection | Yes |
| Palm Authentication Distance | 7" -15.7" (18cm - 40cm) |
| Palm Authentication Posture Adaptability | Yaw ≤ 45°, Pitch ≤ 30°, Roll ≤ 90°, Bend ≤ 30° |
| Palm Authentication Accuracy | - True Accept Rate (TAR) = 98.7%
- False Accept Rate (FAR) = 0.01%
|
| Palm Authentication Mode | 1:1, 1:N |
| Palm Authentication Speed | < 140ms (Field Test Result) |
| Palm Authentication Liveness Detection | Yes (Infrared Light Mode) |
| Recommend Installation Height | - 55" (140cm) (Using the plate with tilt angle)
- 59" (150cm) (Plate with horizontal angle)
|
| Transaction Buffer | Records: 1,000,000 |
| Access Group | 99 |
| On-Board Access Point Control | 1 access point on board |
| On-Board Reader Support | 1 (OSDP over RS-485) or 1 (Wiegand Input) |
| Protection / Resistance | Weather and Dust Proof Protection Rating compliant with IP66 |
